Products
We die-cut Tyvek® lids, HDPE cards, film parts and sheets in our ISO Class 8 cleanroom. We supply the rollstock, pouches and bags that complete the system, sourced from qualified manufacturers in North America and Europe. Everything goes on one quote, one PO and one invoice.
01 · 1 product
Die-cut lids seal onto rigid trays in PETG, PVC, HDPE, HIPS, and PP, with the coating matched to your tray. We cut them in-house from heat-seal coated Tyvek® 1073B, the heaviest and strongest medical Tyvek® grade, so they suit heavy or sharp devices such as orthopedic implants and surgical kits. Choose them with or without a peel tab, printed or unprinted.
More about die-cut lidsHeat-seal coated Tyvek® 1073B lids, die-cut in our ISO Class 8 cleanroom, with a coating matched to your PETG, PVC, HDPE, HIPS, or PP tray.
02 · 2 products
Mounting cards (also called insert cards) are rigid, 100% virgin HDPE, 10–35 mil (0.25–0.89 mm), for chevron pouches and rigid trays. Film components are flexible medical-grade HDPE/LDPE, 28–60 µm (≈1.1–2.4 mil), for liners, protective layers, and interleaves. We cut both in-house, so they ship with your lids and sheets.
More about die-cut components and cardsRigid HDPE cards, 10–35 mil (0.25–0.89 mm), die-cut in our cleanroom to hold and protect devices in chevron pouches and rigid trays.
Flexible HDPE/LDPE film parts, 28–60 µm (≈1.1–2.4 mil), die-cut in our cleanroom: liners, protective layers, and interleaves.
03 · 1 product
Uncoated Tyvek® sheets are cut in-house to custom shapes with rounded corners, up to 30 × 30 in (762 × 762 mm). They have no heat-seal coating and are compatible with EtO, gamma, and e-beam. Order a few sheets for a prototype or a full production run. There is no minimum order.
More about sheetsUncoated Tyvek® sheets cut to custom shapes with rounded corners, up to 30 × 30 in (762 × 762 mm). No minimum order.
04 · 5 products
If you run your own lidding, pouch-making, or form-fill-seal equipment, you need material on the roll. We supply heat-seal coated Tyvek® 1073B and 2FS, medical-grade sterilization paper, coated medical paper, latex-free cold-seal paper, and medical-grade HDPE/LDPE film. Order it on the same purchase order as your die-cut lids and cards.
More about rollstockHeat-seal coated Tyvek® rollstock, 2FS at 71 gsm and 1073B at 86 gsm with coating, for tray lidding, blister lidding, and pouch stock.
100% cellulose medical-grade sterilization paper, 60 and 70 gsm (37 and 43 lb), with grades for steam, EtO, and gamma.
Heat-seal coated medical-grade paper in 60, 70, and 100 gsm, with grid, allover, or pattern coatings for a clean peel with minimal fiber tear.
40 gsm (25 lb) paper with a latex-free cohesive cold-seal coating that seals without heat. Suited to gloves, dressings, and syringes.
Medical-grade HDPE/LDPE film rollstock, 28–60 µm (≈1.1–2.4 mil), for pouch and bag making, form-fill-seal webs, and liners.
05 · 4 products
Chevron pouches have a V-shaped seal that starts a controlled, low-force peel. Choose Tyvek® for a clean, low-particulate peel, paper for economy and print, or foil for a near-total barrier to oxygen, moisture, and light. Header bags carry bulky or heavy devices and kits. Pair any of them with HDPE cards cut in our cleanroom.
More about pouches and bagsPre-made chevron pouches with Tyvek® on one side and PET/PE or PA/PE film on the other, for a clean, controlled peel and aseptic presentation.
Chevron pouches in medical paper and PET/PE film, with a good print surface, usually at a lower cost than Tyvek® pouches.
PA/Alu/PE foil chevron pouches with a near-total barrier to oxygen, moisture, and light, for sensitive devices, diagnostics, and reagents.
100 µm (≈4 mil) LDPE bags with a porous Tyvek® header for sterilant exchange. Heavy-duty gauge for bulky or heavy devices and kits.
Compare
Format, material, weight or thickness, who makes it, and the sterilization methods each product is compatible with. Where the answer depends on grade or package design, see the full chart.
| Product | Category | Format | Material | Weight, gauge or size | Made | Sterilization |
|---|---|---|---|---|---|---|
| Coated Tyvek® lids | Die-cut lids | Die-cut eaches | Heat-seal coated Tyvek® 1073B | 86 gsm (coated 1073B) | Cut in our cleanroom | EtO, gamma, e-beam |
| HDPE cards | Die-cut components and cards | Die-cut eaches or rollstock | 100% virgin HDPE | 10–35 mil (0.25–0.89 mm) | Cut in our cleanroom | EtO, gamma, e-beam |
| HDPE/LDPE film components | Die-cut components and cards | Die-cut eaches | Medical-grade HDPE/LDPE film | 28–60 µm (≈1.1–2.4 mil) | Cut in our cleanroom | EtO, gamma, e-beam |
| Uncoated Tyvek® sheets | Sheets | Die-cut eaches | Uncoated Tyvek® 1073B | 75 gsm uncoated Tyvek® | Cut in our cleanroom | EtO, gamma, e-beam |
| Coated Tyvek® rollstock | Rollstock | Rollstock | Heat-seal-coated Tyvek® 1073B and 2FS | 2FS 71 gsm, 1073B 86 gsm (incl. coating) | Supplied by CleanCut | EtO, gamma, e-beam |
| Medical paper | Rollstock | Rollstock | 100% cellulose medical-grade paper | 60 and 70 gsm (37 and 43 lb) | Supplied by CleanCut | EtO, gamma (by grade), steam (by grade) |
| Coated medical paper | Rollstock | Rollstock | Coated medical-grade paper | 60, 70 and 100 gsm | Supplied by CleanCut | EtO |
| Cold-seal paper | Rollstock | Rollstock | Latex-free cold-seal paper | 40 gsm (25 lb) | Supplied by CleanCut | |
| HDPE/LDPE film rollstock | Rollstock | Rollstock | Medical-grade HDPE/LDPE film | 28–60 µm (≈1.1–2.4 mil) | Supplied by CleanCut | EtO (conditional), gamma, e-beam |
| Tyvek® chevron pouches | Pouches and bags | Pre-made eaches | Tyvek® with PET/PE or PA/PE film | Tyvek® 1073B with 12/50 µm PET/PE film | Supplied by CleanCut | EtO, gamma, e-beam |
| Paper chevron pouches | Pouches and bags | Pre-made eaches | Medical paper with PET/PE film | 60 gsm paper with 12/40 µm PET/PE film | Supplied by CleanCut | EtO, gamma (by grade), steam (conditional) |
| Foil chevron pouches | Pouches and bags | Pre-made eaches | PA/Alu/PE foil laminate | PA 12 µm / Alu 9 µm / PE 75 µm | Supplied by CleanCut | gamma, e-beam |
| Header bags | Pouches and bags | Pre-made eaches | LDPE film with a Tyvek® header | 100 µm (≈4 mil) | Supplied by CleanCut | EtO, gamma, e-beam |
Choosing, or matching?
Use the material selector for a quick shortlist. If the material is already specified, send the spec and we'll quote it as written. For anything else, send a technical question and our team will reply.
